Powder electrostatic spray gun is a small electrostatic powder spraying tool designed for laboratories, suitable for various powder spraying needs such as small amounts of medicine, micro powder spraying, multi-layer powder spraying experiments, material anti-corrosion testing on metal surfaces, small amount spraying color modification DIY coating, etc.
Small and lightweight: convenient for handheld operation and flexible movement in the laboratory, suitable for spraying and sampling small workpieces or small areas.
High powder utilization rate: electrostatic adsorption reduces powder scattering, and the powder cup is designed at the bottom of the spray gun handle, making it convenient for sales to replace powder.
Diverse adjustment functions: powder content 50-280g/min, static voltage 10-100kv adjustable to meet different powder spraying requirements.
Good electrostatic effect: can make the powder fully charged, produce strong electrostatic adsorption force, ensure the powder is evenly and firmly attached to the surface of the coated object, improve the quality of spraying.
Material research: used for the study of surface modification of new materials, such as functional powder coating on the surface of metal, ceramic and polymer materials to improve the surface properties of materials, such as wear resistance, corrosion resistance, conductivity, etc
Product development: small batch spraying samples are carried out in the new product development stage to quickly verify the appearance, performance and process feasibility of the product, such as the preliminary research and development of electronic product shells, auto parts, etc.
Teaching experiment: Materials science, chemical engineering, mechanical engineering and other related majors in universities and scientific research institutions are used for teaching experiment, so that students can understand the principle and process of electrostatic spraying.
V09Y Electrostatic Spray Gun:
|
Parameter name |
Parameter details |
Parameter name |
Parameter details |
|
time to market |
In 2022 |
input voltage |
Single phase AC100-240V |
|
place of production |
China |
incoming frequency |
50-60Hz |
|
Charging mode |
Use AC AV220V |
interiorinput power |
40W |
|
Whether it is rechargeable |
deny |
Maximum output voltage of spray gun |
20-100 kV |
|
Duration of use |
Sustainable use |
Maximum output current of spray gun |
150uA |
|
Arc spray diameter |
15-280mm |
Spray powder adjustment range |
50 -280 g/min |
|
Ejection distance |
300mm |
Powder particle size range |
10-150μm |
|
Powder bucket capacity |
250ml 500ml |
air flow rate |
0-130L/min |
|
Single spray gun weight |
550g |
Single spray gun size |
Length 340mm × width 70mm × height 360 mm |
Powder quantity parameter:
|
Parameter name |
Air simulation display values |
Air flow (L/min) |
Powder output (g/min) |
|
Pressure, flow rate, powder quantity |
Friction Electrostatic Powder Spraying Tools are suitable for various laboratory powder spraying needs, such as a small amount of medicine spraying, micro powder spraying, powder multi-layer spraying experiments, anti-corrosion tests of materials on metal surfaces, small amount of spraying for color-changing DIY coatings, etc.
No power supply, no electrostatic spark, powder friction electrostatic spraying gun. Secondary coating backspray workpiece coating sticky powder rate is high, will not be electrostatic breakdown pinhole concave point, primary spraying groove, safe and efficient. Suitable for laboratory materials spraying test, home DIY hub auto parts color change electrostatic powder spraying best tool. This Small Electrostatic Spray Gun is designed for laboratory small electrostatic powder spraying tools, including small - amount powder spraying, powder multi - layer spraying experiments, corrosion tests on the metal surface of materials, small - amount color - change DIY electrostatic spraying, and other laboratory powder spraying requirements. It is small, light, and portable for operation, allowing for flexible movement in the laboratory. With an internal DC12V lithium - battery power supply and gas pump, it is easy to carry out and suitable for spraying proofing of small parts or small areas. Small Powder Friction Electrostatic Spray Gun is specially designed for laboratory small electrostatic powder spraying tools. It is suitable for small - amount medicine spraying, trace powder spraying, powder multi - layer spraying experiments, material anti - corrosion tests on the metal surface, small - amount spraying color - change DIY coating, and other laboratory powder spraying requirements.
No power supply, no electrostatic spark, powder friction electrostatic spraying gun. Secondary coating backspray workpiece coating sticky powder rate is high, will not be electrostatic breakdown pinhole concave point, primary spraying groove, safe and efficient. Suitable for laboratory materials spraying test, home DIY hub auto parts color change electrostatic powder spraying best tool. This small electrostatic spray gun is designed for laboratory small electrostatic powder spraying tools, a small amount of powder spraying, powder multi-layer spraying experiment, materials on the metal surface corrosion test, small amount of color change DIY electrostatic spraying and other laboratory powder spraying requirements. Small portable handheld operation and flexible movement in the laboratory, using DC12V lithium battery power supply to carry out, suitable for small workpiece or small area of spraying proofing. Intelligent Small Powder Electrostatic Spray Gun is a portable spraying equipment designed for small-scaleproduction, laboratory research and precision machining scenarios. lt integrates intelligent control, highperformance and compact design, perfect for workbenches, research and development laboratories or smallproduction lines with high space requirements。
1.The equipment comes with three formulas: plate surface coating, rework coating and dead corner surface coating, as well as 21 spraying procedures, enabling high-quality workpiece coating; it also features anautomatic qun cleaning function.
2.The control unit offers simple and clear operation for more convenient manaqement. Powder volume,atomization and cleaning adjustments are achieved via electronic touch, with the motherboard controllingthe inlet high-precision control valve to ensure accurate and constant air flow, thus quaranteeing precisepowder output and consistent spraying effects. Powder static spray gun is a powder spraying tool specially designed for small laboratories. It is suitable for a small amount of medicine, trace powder spraying, multi-layer powder spraying experiment, metal surface material anti-corrosion test, a small amount of spraying color change DIY coating and other laboratory powder spraying needs.
Compared with air fluidized powder supply, vibration powder supply is more environmentally friendly. Powder does not fly around, which is more suitable for dust-free operation in laboratory Our hours Monday - Saturday: 8:00 AM - 6:00 PM |
